46 Inch Hd Lcd Advertising Digital Signage Video Wall 1920x1080

  • Description
Product Detail

Quick Details

Place of Origin: Guangdong, China (Mainland)

Brand Name: DDW

Model Number: DDW-LW460HN07

Type: TFT

Application: Indoor

Panel Size: 46inch

Max Resolution: 1920x1080

Viewing Angle: 178x178

Pixel Pitch: 0.76125x0.76125mm

Color: 8Bit,16.7M

Contrast Ratio: 4000:1

Brightness: 450nits

Response Time: 5ms

Bezel width: 5.3mm

Video wall screen brightness: 450nits

Screen contrast: 4000:1

Video wall screen surface: anti-glare

Video wall screen backlight: CCFL

Application condition: indoor and semi-outdoor

Control method: RS232 control

Daisy chain: RJ45 loop

Power consummtion: 230W

Signal support: DVI/HDMI/VGA/AV/YPBPR

Input Voltage: 230W

Packaging & Delivery

Packaging Details: quality carton with full wood box packing

Delivery Detail: 3 working days

Specifications

LCD lcd video wall

-46",5.3mm Ultra narrow bezel

-1920x1080 resolution

-LED backlight 450nits brightnes

-100% New Samsung screen

Origianl Samsung DID panel

5.3mm ultra narrow bezel lcd lcd video wall screen

The world first &Best seller lcd video wall screen!!

Most cost-effective lcd lcd video wall solution screen in the world

Model No.:DDW-LW460HN07

Product Description

46" lcd video wall features:

1,Original Samsung Industrial grade Samsung lcd lcd video wall solution screen 46inch,16:9 LG a-Si TFT-LCD

2,450nits brightness,4000:1 contrast

3,HD physical resolution 1920x1080

4,Only 5.3mm Ultra narrow bezel.high quality ,Practical ,good vision effect.

5,Signal interface rich --- RS232, HDMI,DVI,VGA,Y Pb Pr ,AV

6,HD lcd video wall unit--- High brightness,high contrast,High gamut .

7,Flexible structure design ---easy installation ,extensible,arbitrary combination

8,Stable performance,suitable working for a long time

46" lcd video wall is one of Samsung most popular Lcd lcd video wall panels which has 6.7mm ultra narrow bezel,FHD1920x1080  resolution,and 700nits brightness,it's one of first Samsung general videowall panels in the world. Samsung lcd videowall can be used in below fields: Conference and meeting rooms, office building, lobbies, Security Monitoring Center, Surveillance and Retail Center, Restaurant and hotel, Retail Shopping Mall Advertising and information Displays, Public Installations, Exhibition and show center, Live show,Rental and advertising Center,Museums,Church,Transportation and Mass Info Display systems.

Specifications

LCD Video wall Panel Specifications
LCD TechnologySAMSUNG DID LCD
Active Screen Diagonal46"  16:9
Bezel WidthTotal: 5.3mm
Aspect Ratio16:9
Physical Resolution1920x1080
Backight SystemCCFL
Luminance(nits)450cd/sqm
ContrastMEGA DCR
Viewing AngleH 178°|V 178°
Pixel Pitch(WxH)0.76125×0.76125mm
Active Display Area(WxH)1039.8675×584.64 mm
Panel Dimension(WxHxD)1046.8×591.6x49.5mm
White Point10,000 K
Display Colors8Bit,16.7M
Refresh Rate60Hz
Response Time<=6ms
Life(hrs)>60,000(hrs)
MTBF> 100,000 h
SurfaceAnti-glare
Standby Power Consumption<3W
Maximum Power Consumptionlower than 250W
Power SupplyAC100~240V 50/60 HZ
CoolingLow noise fans
Heat Dissipation819 BTU/h (max)
Working Time Capacity7x24x365hours
Application AreaIndoor/Semi Outdoor
Working Temperature0°C~50°C
Working Humidity0.85
Storage Temperature-20-60°C | -4-140°F
Storage Humidity85% non-condensing
Daisy chain lcd video wall controller specifications
DVI-I DUAL LINK1
HDMI1
VGA1
CVBS IN1
CVBS OUT1
RS232 IN1
RS232 OUT2
ISP IN1
IR IN1
CODING BUTTON1
AC INAC100-240V
Color System SupportPAL/NTSC/SECAM
Control TypeIR Remote &Software Control
Menu LanguageEnglish/Chinese(Multiple Language can be customized)
Vertical/Horizontal DisplaySupport
Combine DisplaySupport combine any horizental &vertical numbers of screens and show display
 Support combine all screens together to show 1image
Solid DisplaySupport each screen input with separate signal
PIP/Zoom/RoamingSupport open one window for each screen, each window can be zoomed &roaming internal freely
Multiple InterfacesSupport DVI,HDMI,VGA,AV &multiple signal inputs
Rich ResolutionSupport 1080P,1080I,720P,480P &multiple resolution inputs
Dimension(WxHxD)318.4x332x56mm
