SJM35 Machine Screw Jack Mechanism

  • Description
Product Detail

SJM35 Machine Screw Jack Detailed Information:

1. Jack Model: SJM35

2. Screw Diam.: 100mm

3. Screw Pitch: 18mm

4. Max load capacity: 350KN

5. Speed Ratio: 3/32, 1/32

6: Max permissible power: 13.06KW

7. Top End: top plate, clevis end, threaded end, plain end


SJM35 Machine Screw Jack Specification:

SJM35 Machine Screw Jack ( Tr100×18)


Speed

(rpm)


Lifting Speed

(mm/min)

F=350KN

F=300KN

F=250KN

F=200KN

H

L

H

L

H

L

H

L

464 N.m

253 N.m

398 N.m

217 N.m

332 N.m

181 N.m

266 N.m

145 N.m

H:3/32

L:1/32

(KW)

(KW)

(KW)

(KW)

(KW)

(KW)

(KW)

(KW)

1500

1500

500

49

27

42

23

35

19

28

16

1000

1125

375

37

20

32

17

26

15

21

12

750

750

250

25

14

21

12

18

9.5

14

7.6

500

600

200

20

11

17

9.1

14

7.6

12

6.1

300

450

150

15

8.0

13

6.8

11

5.7

8.3

4.5

200

300

100

9.8

5.3

8.4

4.5

7.0

3.8

5.6

3.0

100

150

50

4.9

2.7

4.2

2.3

3.5

1.9

2.8

1.5

50

75

25

2.5

1.3

2.1

1.1

1.8

0.9

1.4

0.8


Speed

(rpm)


Lifting Speed

(mm/min)

F=150KN

F=100KN

F=50KN


H

L

H

L

H

L



199 N.m

109 N.m

133 N.m

73 N.m

67 N.m

36 N.m



H:3/32

L:1/32

(KW)

(KW)

(KW)

(KW)

(KW)

(KW)



1500

1500

500

21

12

14

7.6

6.9

3.8



1000

1125

375

16

8.5

11

5.7

5.2

2.8



750

750

250

11

5.7

6.9

3.8

3.5

1.9



500

600

200

8.3

4.5

5.6

3.0

2.8

1.5



300

450

150

6.3

3.4

4.2

2.3

2.1

1.1



200

300

100

4.2

2.3

2.8

1.5

1.4

0.8



100

150

50

2.1

1.1

1.4

0.8

0.7

0.4



50

75

25

1.0

0.6

0.7

0.4

0.3

0.3
