Two-color Striped Film Blowing Machine

  • Description
Product Detail

Two-color Striped Film Blowing Machine Product Details :

   Use:

The Double Die Head Two-Colour Striped Film Blowing Machine Set is composed with two screw stemsand cylinder with onedie head, it adopts the device of two different plastic materials, which can blow different kinds of striped vest bags (shopping bag), it can get colorful bags without pringting ,with such features as beautiful colors, average stripe, logical structure, advancedtechnology, even rewinding and high output.

     Feature:

1. The full set machine is made of twosets main motors, two cylinders and one layer die head, feeding by two cylinders. Extruding with one die head one traction and rewinding device , it can improve the quality of striped film by adopting with one traction and one rewinding device.
2. The screw stem and cylinder ate made of 38CrMoAl high quality alloy steel after fine finishing and nitrided treatment, which has high hardness,strong resistance to corrosion, durable service.
3. The die head is plated with hard chrome ,of screw mandrel type structure with even and smooth discharging, the blownplastic film has fine finishing ,the blower is of labyrinth structure with even air output.
4. The coiling unit adopts pressutre friction rewinding or center rewinding , which is driven bytorque motor , with even and smooth rewinding and easy roll changing.


     Technical Parameters:

Type

SJ-45×2

SJ-55×2

Diameter of Screw

45mm×2

55mm×2

Screw L/D Ratio

28:1

28:1

Screw Spead

10-110r/min

10-110r/min

Max.Output(kg/h)

45kg/h

60kg/h

Max.Layflat Width (mm)

550mm

650mm

Film Thickness(mm)

0.006-0.10mm

0.006-0.10mm

Power of Main Motor

11kw

18.5kw

Total Power

30kw

40kw

Weight of Machine

2200kg

3000kg

Overall Dimensions(L×W×H)mm

4800×2200×3600

5000×2400×4200
